Concrete Pad Specifications For Generators

Any installation should be completed in accordance with the local building codes.

Concrete pad specifications for generators.

The pad should be flat and level to within inch. L54 x w31 x h3 189lbs. Our new lightweight oval pad for air cooled generators is pre drilled for easy mounting. Genpads come in 3 and 4 heights.

The oval design blends well with the classic contours of larger estates. A common specification for a concrete pad is 2500 psi compression strength concrete reinforced with 6 rebar on 12 inch centers. Curing takes up to a week for full strength. No technical specifications or downloads available for this product.

Mounting pad weight should be at least the total weight of the generator set and its mounted accessories mounting pad specifications standard practice is 2500 3000 psi is for concrete reinforced with eight gauge wire mesh of 6 reinforcing bars on 12 centers. Mixed concrete is poured into a form and allowed to harden. The pad can be installed on level ground leveled pea gravel or a concrete pad. The standard genpad is ideal for most residential applications.

32 x 54 x 4. Technical specs downloads. Our standard pad 250 lbs can be ordered in most any size. The specification with 2500 3000 psi is for concrete reinforced with eight gauge wire mesh of 6 reinforcing bars on 12 centers.

The composition of the mounting pad should follow standard practice for required load bearings. The depth of the pad is calculated as 125 of the unit wet weight fuel included. Multiple pads can be installed side by side for larger generators or other heavy items or stacked for heavier loads. 54 x 31 x 3 190 lbs.

The process is simple. This pad should be seated on a solid subsurface. Generator concrete pad mixture. It is contoured to look aesthetically pleasing with a wide range of common residential generators and comes in multiple bolt configuartions.
